Part # 30167600-602
Wunderlich Extreme Slimline Case Set
Available in: Aluminum or Black

Available in: Aluminum or Black

From now on we are also offering our EXTREME case sets in a slimline version that is 80 mm (40 mm per side) narrower - which still has an impressive 71 liters of storage volume - compared to 85 liters with the normal EXTREME case set.

In busy metropolises, in traffic jams or in narrow streets, you can elegantly “surf” through traffic without having to worry about bumping into other road users or obstacles. The slimline version can also be an advantage in demanding off-road passages. Because the handling is also noticeably more agile - compared to driving with conventional cases - thanks to the more favorable center of gravity of the slimline cases, not only off-road.
In the 1980s, adventure trips still required a great deal of preparation and, above all, a lot of storage space. Tire repair kits, smartphones, apps, credit cards and much more meanwhile make a lot of things easier, so that you can certainly set off on an adventure trip with less luggage on your bike. If you want this.

Our stable, light and stylish EXTREME slimline aluminum cases go with you through thick and thin! Attaching to the carrier is uncomplicated thanks to the quick-release system. Thanks to their special sealing system, they are absolutely dust and watertight. The consistent use of only high-quality materials ensures the longevity of our "EXTREME" luggage system. The processed 1.5 mm aluminum sheet with stabilizing beads (weight-optimized, yet robust), the stainless steel fittings, the exchangeable all-round protection at all corners and the protective caps for the locks contribute to this.

Thanks to the additional lashing eyes on the lid, additional items of luggage - for example our Rack Pack bags - can be securely strapped on. The case lids are equipped with practical luggage nets on the inside as standard, for everything that needs to be within easy reach on the go: rain gear, tools or the first-aid kit.

After opening both hinged locks at the front and rear, the lid can be completely removed and the cases can be conveniently loaded from above. If only one of the two locks is opened, the second lock serves as a kind of hinge. The lid can be opened to the front or to the back and is held in place by a safety rope.

The version in untreated aluminum is something for purists who appreciate the material and appearance of the original, untreated and robust material.

Keyed alike locking cylinders – please order separately

So that you only need one key for your luggage system, we offer keyed alike locking cylinders. You need a couple of locking cylinders per case/top ase. Please order the desired number of locking cylinders for your cases/top case:

• 30167-500 A pair of lock cylinders (e.g. for a top case)
• 30167-501 Two pairs of lock cylinders (e.g. for the case set)
• 30167-502 Three pairs of lock cylinders (for case set and top case)

Matching pannier rack

Our EXTREME and EXTREME slimline cases fit the original BMW Adventure case carrier. For the other GS models we offer suitable EXTREME pannier racks as follows:

• 30167-001 Pannier rack R 1200 GS LC/R 1250 GS
• 30167-101 Case carrier F 750/F 850 GS
• 90600000  Pannier Rack Set Harley Davidson - Pan America/Special


Function

• EXTREME slimline – the cases that are 80 mm narrower and still offer a total storage volume of 77 liters – ideal for urban zones with high traffic density or in demanding off-road passages
• The handling is noticeably more agile thanks to the more favorable center of gravity of the slimline cases, compared to driving with conventional cases
• Top loading: Easy to load from the top
• Lids can be opened either forwards or backwards or removed completely
• Closure system made of stainless steel including a discreet embossed Wunderlich brand logo
• 100% dustproof and waterproof thanks to a special seal
• Lashing eyes on the lid for additional luggage
• Cutout system (recess for the exhaust)
• Replaceable corner protection made of impact-resistant plastic
• A pair of locking cylinders are required for each case
• Locking cylinders are protected against dirt, dust and moisture by removable rubber cover caps
• Cases fit the original BMW Adventure case carrier
• We offer matching pannier racks for the other GS models

Technical specifications

Material:

• Aluminium, high-strength, pure/untreated, carefully and precisely processed
• Fittings - fasteners, screws and rivets - made of stainless steel
• Dimensions:
• 440 x 240 x 390 mm (width x depth x height) (left and right)
• Material Thickness: 1.5mm

volume

• Left suitcase 38 liters, right suitcase 33 liters
• Total: 71 liters

color

• Pure Aluminium or Black


Vehicle width with EXTREME slimline cases

• R 1250 GS approx. 92 cm with Wunderlich pannier rack
• R1250 GS Adventure approx. 92 cm with original Adventure pannier rack
• R 1200 GS LC approx. 92 cm with Wunderlich pannier rack
• R 1200 GS LC Adventure approx. 92 cm with original Adventure pannier rack
• F 850 GS approx. 92 cm with Wunderlich pannier rack
• F 850 GS Adventure approx. 92 cm with original Adventure pannier rack
• F 750 GS approx. 92 cm with Wunderlich pannier rack

Your Wunderlich benefits

• Popular product. Small series. Made by hand.
• Epic design. Functional and integrated.
• Exclusively by Wunderlich
• Tested by Wunderlich
• Made by Wunderlich
• Made in Europe

Fits To

The following Wunderlich bags can be used in combination with the cases:

• 25180-102 Rack Pack Wunderlich Edition
• 25181-002 Wunderlich Rack Pack WP40
• 20790-xxx Top bag BagPacker ll black
• 43740-000 Wunderlich inner bag »EVO«
