Part # 31671002
Wunderlich Engine Bars, Black

I only bought these for my 14 F800GT so I could put highway pegs on to stretch my legs. The directions aren't well translated from German and the bottom 2 bolts on the engine are extremely difficult to line up and install. Took me and a fellow F800 owner almost 4 hours to install with quite a selection of tools and much contorting of our bodies. They have an odd 26mm diameter and a weird angle compared to your seating position so highway pegs are at a non ideal location and difficult to find.

In hindsight I should have read these reviews before starting to install the guard. The first thing that they should tell you is that you need to cut away the inner fairing on both sides to access the mounting holes. Also it is much easier with 2 people to achieve better alignment and not scratch the fairing paint. Third, it is impossible to tighten the lower bolt with a torque wrench because the guard is in the way of achieving a straight angle to the bolt. That being said I did complete the job by myself. My only concern is the right side mounting bracket rubbing against the radiator hose so I will install a heavier pad there.

The installation instructions do not fully reflect the fairing modifications that are needed. Aligning the lower mounting points to properly thread the bolt into the engine is a difficult process that benefits from a lift and a second person. It is better to thread the lower mount first then attach the top mount (instructions for single person installation suggest the reverse). Otherwise a great product once installed
